Chloride Sensor with Electrode

Each sensor requires a sensor cable to connect to LabMate+ or Tablet+. Sensor cable sold separately.

The Chloride Sealed Electrode measures total free chloride in aqueous solutions and is a PermaFil (non-refillable), Ion-selective electrode – the reference chamber is gel filled and sealed. No reference fill solution is required. The Chloride Electrode set consists of a PermaFil combination electrode, which combines the Ion-selective electrode and the reference electrode as well as Fourier’s ISE amplifier.

Specifications:

Concentration Range: 1 M to 5 x 10-6 M or 1.8 ppm to 35,500 ppm
Resolution (12-bit): 0.15 mV
pH Range: 2.0 to 12.0 pH
Temperature Range: 0 to 80 degC
Minimum Sample Size: 3 mL in a 50 mL beaker
Reproducibility: ±2 %
Default Sample Rate: 10 samples per second
Electrode Resistance: Less than 1 MΩ
Interfering Ions: CN-, Br-, I-, OH-, S2-

Measurements are approximate.
